Steel Twin Tube Coilover Shock Absorber 8 Stage Adjustment For Mazda BT50





Toptiger 4x4 coilover shock struts feature a threaded body for ride height adjustment. It may be neccessary to unload the spring tension before making adjustments.



Many independent suspension systems incorporating struts operate at a 2:1 motion ratio.



For every 1mm of movement (compression or extension) at the strut, equates to 2mm movement when measured at the wheel. This MUST be considered when adjusting seat height.



Raising ride height too high can damage the suspension components, impair suspension operation and safety.







Mazda BT50 2011+











8 stage adjustment
Allow for adjustability of compression, The result is a ride customisation that can be tailored to individual vehicle or trip requirements.



Twin-Tube internal design

Allows greater oil volume for cooling and sustained valving performance and strong 1.6mm outer tube construction protects the vital internal components from damage.





Performance shock absorber oil

High-performance oil and nitrogen gas combine to reduce aeration and make the shock more durable in harsh conditions. The gas pressure keeps the oil cohesive under all situations.





Rod Diameter	18mm
Bore & piston	36mm
Outer Shell	57mm
Weight	13.8kg
Front Travel	13.9cm
Rear Travel	23.9cm
Box Size	20*20*58
SKU	TKG8020-CO
Warrnty	One year/20,000km



Before installation and use of Toptiger ATG series Nitrogen gas charged shock absorbers, please refer to the instructions attached to the product package or call manual customer service. Under the condition of correct installation and use of Toptiger’s products, the brand will give you one-year warranty for products with quality problems. If you have any warranty problems, please contact the purchase dealer or installation point.
